| Brand Name : | GUOMAT |
| Model Number : | F-300-4 |
| Certification : | ISO/TS16949, ISO9001 |
| Price : | Negotiable |
| Payment Terms : | L/C, D/A, D/P, Western Union |
| Supply Ability : | 1000PCS/Week |
| Delivery Time : | 5-8 Working Days |
S-300-4R YOKOHAMA Industrial Air Spring 206mm Natural Height Air Rubber With Waist Ring
Part Number
AIRSUSTECH Part No.: F-300-4
YOKOHAMA S-300-4R
YOKOHAMA S 300 4R
YOKOHAMA S-300-4
Product Application
| GUOMAT | YOKOHAMA | Height H (mm) | Common Max.Stroke | Compression Max OD | Approximate values at standard height and internal pressure of 0.49 MPa | Use maximum internal pressure | ||||
| Natural Height | Max.Height | Min.Height | Effective area | volume | load | |||||
| F-300-4 | S-300-4 | 206 | 326 | 111 | ±80 | 360 | 710 | 15.5 | 34.7 | 0.88 |
| F-300-3 | S-300-3 | 152 | 242 | 82 | ±60 | 360 | 710 | 11.2 | 34.7 | 0.88 |
| F-300-2 | S-300-2 | 98 | 158 | 53 | ±40 | 360 | 710 | 7.4 | 34.7 | 0.88 |
| F-300-1 | S-300-1 | 72 | 117 | 40 | ±30 | 400 | 710 | 5.6 | 34.7 | 0.69 |
Advantages Compared to Mechanical Springs
Constant pressure: Within its stroke range, air springs provide a very stable force, while the force of a mechanical spring varies with compression.
Adjustable pressure: Output force can be easily changed by simply adjusting the intake pressure, adapting to different molds and processes.
Long stroke: Compared to a mechanical spring of the same size, air springs have a longer effective working stroke.
Long lifespan: High-quality air springs can last for millions of cycles, far exceeding the lifespan of mechanical springs.
Flexible installation: Compact design, easy to arrange in molds.
The Related Picture of F-300-4


|
